Bitcoin Ordinals: SVG vs SVGZ
The SVG in the image above is 106,852 bytes. Gzipped, it is 32,319 bytes, and that is what I inscribed on Bitcoin in October 2023, along with a 928-byte HTML inscription that decompresses it and displays it. The two together take 33,247 bytes of block space, 69% less than the SVG alone would have. I posted the idea on X on October 2 and the working result as a thread on October 6; this is the write-up with the code in it.
An SVGZ is an SVG compressed with gzip. Vector art is text (mostly path coordinates), and text compresses well; 50-80% smaller is the range I have seen on SVGs. The problem is how the browser learns that it has been sent compressed data. A web server serving an .svgz file adds a Content-Encoding: gzip header and the browser decompresses before it renders. An inscription carries a content type and nothing else, so ordinals.com served my first SVGZ (inscription 34963011, October 1) as image/svg+xml with the gzip bytes as the body. The browser tries to parse compressed binary as XML and shows an error where the image should be.
So the SVGZ needs a second inscription that fetches it, decompresses it in JavaScript, and puts the result on the page. Recursion makes that cheap, since an inscription can load any other inscription from /content/<id>. The decompressor was already on-chain: boppleton had inscribed pako 2.1.0, a JavaScript port of zlib, as an ES module in August 2023 (47,663 bytes), so the loader imports that instead of carrying its own copy.
The first loader, inscription 35084623, displayed on ordinals.com and showed nothing on ord.io or Gamma. It fetched pako as text, turned it into a data: URL, imported the module from that URL, and handed the decompressed SVG to an <embed> as a second data: URL. ordinals.com's Content Security Policy allows data: URLs. The policies on those two sites were stricter and did not.
After several rewrites, the version that displayed on every Ordinals site and wallet I tested is inscription 35118062:
<html>
<body style="margin:0px;">
<div id="svg-container"></div>
<script>
async function displaySvg() {
const svgzUrl = '/content/62a77ef2f8fa7caaa237c36cd7404d1a46918c074d79bb73228108d7e0968b11i0';
const response = await fetch(svgzUrl);
const compressedData = await response.arrayBuffer();
const module = await import('/content/fba6f95fb1152db43304a27dce8cb8c65509eba6ab0b6958cedeb33e5f443077i0');
const decompressedData = module.inflate(new Uint8Array(compressedData), {to: 'string'});
const container = document.getElementById('svg-container');
container.innerHTML = decompressedData;
const svgElement = container.querySelector('svg');
svgElement.setAttribute('width', '100%');
svgElement.setAttribute('height', '100%');
}
displaySvg();
</script>
</body>
</html>Everything it loads comes from /content/ on the same origin, and the SVG goes into the page as inline markup instead of through a URL. The two /content/ IDs are the only parts specific to this piece. The art is part of a collab between Twickert and me, and our collab piece released on November 1, 2023 was the first built on this method.
Seven weeks after the thread, ord 0.12.0 (November 24, 2023) added compression to the protocol. ord wallet inscribe --compress compresses the content with brotli, keeps the result only if it is smaller, and records br in the inscription's content_encoding field. ord's server then sends that as a Content-Encoding: br header, and the browser decompresses it with no loader inscription. On this SVG, brotli at its highest setting comes to 28,316 bytes, against 33,247 for the SVGZ and loader together. ord 0.13.0 added a server flag that decompresses brotli before serving it, for clients that cannot handle the header.
The inscriptions, the loader, and pako are all readable at the links above.
